Description

5 Port HDMI AV Switcher

Supports 4K and 3D Formats

This is a high performance 5 HDMI input selector to 1 HDMI output switch. This HDMI switch box supports HDCP repeater functions and fast switching between any of the HDMI ports. HDMI Auto Switch supports all 3D TV formats in addition to all HDTV formats up to 4Kx2K. Furthermore, the remote control gives complete control over the selection of sources and makes the device incredibly user friendly.

Features:

• Compliant with HDMI 1.4a, CTS 1.4a, DVI 1.0 standards.

• HDMI 1.4 support: 3D TV support.
• Support 3D Video & 4Kx2K, 8, 10, 12 & 16 bits per color depth.
• Support Remote control and HDMI auto switch

Audio support:

• Dolby True HD
• DTS-HD Master Audio 7.1CH
• Low power consumption (does not require an external power supply)

Package:

• HDMI 1.4 4by1 Switcher
• USB Power Supply cable
• Remote control
• IR Receiver cable
• Operation Manual

Specifications:

• HDMI Resolution – 24/50/60fs @ 480i – 1080p, 24/30Hz @ 4K 2160P
• Deep Color – 24/30/36bit/1080P/1080i/720p/576p/576i/480P/480i 24bit//2160P
• HDMI In/Out Supported Audio Format – DTS-HD/Dolby-trueHD/LPCM7.1/DTS/Dolby-AC3/DSD
• HDMI Channel Max Bandwidth – 225MHz
• Input / Output DDC signal – 5Vp-p(TTL)
• HDMI Input Cable Length – ≤6m AWG26 HDMI standard cable
• HDMI Output Cable Length – .≤6m AWG26 HDMI standard cable
• Max Working Current – 400mA
• Working Temperature Range – (-0 to +40℃)
• Working Humidity Range – 5 to 85%RH（No Condensation）
